PRODUCT DESCRIPTION

INDUSTRY CASTER WHEEL

Description: Fix, Flexible, Screw, Bolt.
Brake mode: Dual Brake
Housing made of pressed steel, black Lacquer, blue zinc plated.
Wheel install with axle and nut & bushing, Roller bearing
Alternative wheel materials: PU /PP/PA/TPR/RUBBER /Elastic Rubber

TECHNICAL DATA

Detail	3 inch	4 Inch	5 Inch	6 Inch	8 Inch
Wheel diameter (mm)	75	100	125	150/160	200
Tread width (mm)	25	30	37	50	50
Overall height (mm)	96	128	155	195	235
Load Capacity (KGS)	50	100	120Detail	150	180
Size of Plate (mm)	75 x 60	102 x 82	102 x 82	135 x 110	135 x 110
Hole centre (mm)	60 x 50	80 x 60	80 x 60	80 x 60	80 x 60
Installation Mode	Fixed Plate Screw Bolt	Fixed Plate Screw Bolt	Fixed Plate Screw Bolt	Fixed Plate Screw Bolt	Fixed Plate Screw Bolt
